Phabrix LPX500IS 3U Waveform Monitor, 4 IP Inputs, 10GbE x 2, 4 SDI Inputs

$14,060.00

SKU LPX500IS

Available to order — allow extra processing and shipping time

Full manufacturer warranties on everything we sell
14-day returns on new, unopened items
Questions? Talk to a specialist — Mon–Fri 8:30–5 ET

The Leader/PHABRIX LPX500 hybrid IP/SDI waveform monitor is the first in a powerful new family of video analysis and generation instruments, encompassing next-generation technology from the renowned Leader and PHABRIX test and measurement brands. The LPX500 offers a bank of four independent analyzers, enabling simultaneous display and monitoring of up to 4x 12G-SDI and 2x 100GE-IP inputs, in a compact 3U short-depth form factor with an 8-inch touchscreen. Its app-style interface provides enhanced multi-screen layouts with swipe navigation, dual built-in VNC clients for fast remote access, and support for SD/HD/3G/6G/12G-SDI, 10GE/25GE/100GE IP, SMPTE ST 2022-6, ST 2110-10/20/30/31/40 with ST 2022-7, and AMWA NMOS. This LPX500IS configuration adds four 12G-SDI inputs alongside the four IP inputs over dual 10GbE.
