FiDO-2T-MM offers unmatched flexibility and cost efficiency for 3G-SDI Fiber conversion, allowing for cable runs up to 700 m (2296 ft) for OM4 and 300 m (984 ft) for OM3 for Multi-Mode* fiber optic cables - useful for eliminating ground loop problems.

FiDO converters use a compact, low-profile enclosure that works well in tight spaces around and behind equipment racks, trucks and on camera.

Features

• 2-Channel 3G-SDI to Multi-Mode LC Fiber Transmitter
• Duplex connection (LC connector)
• Dual, independent 3G/HD/SD-SDI inputs
• Both SDI-to-Fiber paths are completely independent
• Supports pass-through of SDI metadata, including HDR
• Uses 5-20VDC power (Universal power supply included)
• Five year warranty

HDR Pass-Through Support
HDR or High Dynamic Range, provides the ability to display a wider and richer range of colors, much brighter whites, and much deeper, darker blacks than SDR or Standard Dynamic Range signals allow. This gives your imagery a more ‘dynamic’ look and allows for natural true to life colors to be communicated to your audience.

Tech Specs:
Video Formats: 150 Mbps - 3 Gbps, format agnostic
Video Input Digital: 2-channel independent 3G-SDI BNC Inputs, SMPTE-259/292/424
Video Output Digital: 2-channel independent Multi-Mode LC Fiber Outputs, SMPTE-297; Nominal Wavelength: 850 nm; Optical Power: -7dBm (Min), -2dBm (Max); Extinction Ratio: 7.5dB (Typ)
Reclocking: 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select; All other rates are passed through and not reclocked
Size (w x d x h): 4.6" x 1.71" x 0.85" (117.0 x 43.5 x 21.6mm)
Weight: 0.5 lb (0.3 kg)
Power: 3 watts, max; Uses 5-20VDC power, universal power supply included
Environment: Safe Operating Temperature: 0 to 40 C (32 to 104 F); Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F); Operating Relative Humidity: 10-90% noncondensing; Operating Altitude: <3,000 meters (<10,000 feet)
