Powerful internal HDDs designed for performance, reliability and power efficiency in small to medium NAS environments.

WD Red Plus internal HDDs are designed to handle workloads for power users and small to medium business NAS environments. WD Red Plus drives deliver the speed and capacity required to store, protect and share growing amounts of data in mid-sized RAID-optimized NAS systems with increased power efficiency.

Tuned for NAS with NASware™
Western Digital’s exclusive NASware™ technology fine tunes drive parameters to match NAS system workloads which helps increase performance and reliability.

Designed for Continuous Operation
Since your NAS system is always on, a reliable drive is essential. WD Red Plus hard drives are designed for systems that operate 24x7, giving users the confidence of knowing they can reliably access their data.

Tested for Dependable Compatibility
Western Digital partners with a wide range of NAS system vendors for extensive testing to ensure compatibility with most NAS enclosures.

Optimized for Lower TCO
WD Red Plus drives are engineered to use less power (versus previous models) and run cooler, which reduces operating costs and helps reduce heat in thermally challenged NAS boxes.

Powered for Strong Performance
Despite using less power, the drives have plenty of bandwidth to handle the mixed performance demands of multi-drive NAS systems.

Balanced for Increased Reliability
Hard drives that are not properly balanced may cause excessive vibration and noise in multi-drive systems, which could reduce hard drive life span and degrade the performance over time. Our enhanced dual-plane balance control technology significantly improves balance and increases overall drive performance and reliability.

Backed by World-Class Support and Warranty
As an industry-leading hard drive manufacturer, Western Digital stands behind their NAS storage solutions with the assurance of a 3-year limited warranty and world-class support services for hassle free data storage.

Desktop drives vs. WD Red® Plus
It is important to choose a drive purpose-built for RAID-optimized NAS systems to ensure optimum performance and preserve your valuable data. Take the following into consideration when choosing a hard drive for your NAS:
• Compatibility: Unlike desktop drives, WD Red Plus hard drives are specifically designed and tested for NAS and include NASware™ technology which fine tunes drive parameters to match NAS system workloads for optimum performance.
• Reliability: Desktop drives aren’t typically designed for the demands of an always-on NAS environment. WD Red Plus hard drives are designed to perform under tough conditions encountered in high-intensity 24x7 multi-user NAS environments.
• RAID Ready: WD Red hard drives are engineered with RAID error recovery control to help reduce failures within multi-bay NAS systems, unlike most desktop drives that are configured for generic use.
• Noise and Vibration Protection: Designed to operate solo, desktop drives typically offer little or no protection from the noise and vibration present in a multi-drive system. WD Red hard drives include Rotation Vibration (RV) sensors that anticipate and proactively counteract disturbances caused by increased vibration often found in multi-bay NAS systems.

Capacity

2TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 175MB/s

Disk Speed (RPM)

5400 RPM

Recording Technology

CMR

Cache Size

64MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

720gms

Model Number

WD20EFPX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

• Ideal for Home Offices, Power Users, Small to Medium Businesses and Consumer/Commercial NAS systems
• For RAID-optimized NAS systems with up to 8 bays
• Rated for 180TB/year workload¹ and 1M hours MTBF

Compatibility

RAID-optimized NAS systems with up to 8 bays

Capacity

3TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 180MB/s

Disk Speed (RPM)

5400 RPM

Recording Technology

CMR

Cache Size

256MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

570gms

Model Number

WD30EFPX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Capacity

4TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 180MB/s

Disk Speed (RPM)

5400 RPM

Recording Technology

CMR

Cache Size

256MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

570gms

Model Number

WD40EFPX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Capacity

4TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 180MB/s

Disk Speed (RPM)

5400 RPM

Recording Technology

CMR

Cache Size

128MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

1.21lbs

Model Number

WD40EFZZ

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Capacity

6TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 180MB/s

Disk Speed (RPM)

5400 RPM

Recording Technology

CMR

Cache Size

256MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

750gms

Model Number

WD60EFPX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Capacity

8TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 215MB/s

Disk Speed (RPM)

5640 RPM

Recording Technology

CMR

Cache Size

256MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.79" x 4" x 1.03"

Weight

715gms

Model Number

WD80EFPX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Capacity

10TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 260MB/s

Disk Speed (RPM)

7200 RPM

Recording Technology

CMR

Cache Size

512MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

1.65lbs

Model Number

WD100EFGX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Capacity

10TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 215MB/s

Disk Speed (RPM)

7200 RPM

Recording Technology

CMR

Cache Size

256MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

750gms

Model Number

WD101EFBX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Capacity

12TB

Form Factor

3.5-Inch

Connector

SATA

Interface

SATA

Transfer Rate

up to 260MB/s

Disk Speed (RPM)

7200 RPM

Recording Technology

CMR

Cache Size

512MB

Warranty

3-Year Limited Warranty

Endurance (TBW)

180TB/Year

Dimensions (L x W x H)

5.787" x 4" x 1.028"

Weight

1.65lbs

Model Number

WD120EFGX

Operating Temperature

0°C to 65°C

Non-Operating Temperature

-40°C to 70°C

Product Features

Compatibility

Model Numbers

2TB,64MB: WD20EFPX

3TB,256MB: WD30EFPX

4TB,256MB: WD40EFPX

4TB,128MB: WD40EFZZ

6TB,256MB: WD60EFPX

8TB,256MB: WD80EFPX

10TB,512MB: WD100EFGX

10TB,256MB: WD101EFBX

12TB,512MB: WD120EFGX

Model Numbers

2TB,64MB: WD20EFPX

3TB,256MB: WD30EFPX

4TB,256MB: WD40EFPX

4TB,128MB: WD40EFZZ

6TB,256MB: WD60EFPX

8TB,256MB: WD80EFPX

10TB,512MB: WD100EFGX

10TB,256MB: WD101EFBX

12TB,512MB: WD120EFGX

Disclosures

1. Workload Rate is defined as the amount of user data transferred to or from the hard drive. Workload Rate is annualized (TB transferred ✕ (8760 / recorded power-on hours)). Workload Rate will vary depending on your hardware and software components and configurations.
