24TB

Capacity

5-Year Limited Warranty

Warranty

48TB

Capacity

5-Year Limited Warranty

Warranty

72TB

Capacity

5-Year Limited Warranty

Warranty

80TB

Capacity

5-Year Limited Warranty

Warranty

96TB

Capacity

5-Year Limited Warranty

Warranty

104 TB

Capacity

5-Year Limited Warranty

Warranty

24TB

Capacity

5-Year Limited Warranty

Warranty

48TB

Capacity

5-Year Limited Warranty

Warranty

72TB

Capacity

5-Year Limited Warranty

Warranty

80TB

Capacity

5-Year Limited Warranty

Warranty

96TB

Capacity

5-Year Limited Warranty

Warranty

104 TB

Capacity

5-Year Limited Warranty

Warranty

Transportable, hardware RAID powerhouse for consolidated backup, super-fast access and real-time video editing.

A transportable 4-bay hardware RAID solution with Thunderbolt™ 3 (40Gbps) and USB-C™ (10Gbps) interfaces offering content professionals up to 104TB¹ of massive capacity and high-powered performance for consolidated backup, super-fast access, and real-time video editing. Supports multi-stream 4K, 8K, and VR workflows, RAID 0, 1, 5, and 10 configurations, and provides transfer rates up to 700MB/s read and 850MB/s write² in default RAID 5 (96TB model only). Along with Ultrastar enterprise-class hard drives inside for enhanced reliability and a trusted 5-year limited warranty, the G-RAID SHUTTLE 4 is the ultimate storage solution for demanding video workflows on location and in the studio.

Capacity

24TB

Connector

• Thunderbolt 3
• USB-C

Sequential Read Performance

(In default RAID 0) - Up to 1000MB/s

Sequential Write Performance

(In default RAID 0) - Up to 1100MB/s

Interface

• USB 3.2 Gen 1
• Thunderbolt 3

Disk Speed (RPM)

7200 RPM

Dimensions (L x W x H)

9.75" x 6.85" x 10.5"

Warranty

5-Year Limited Warranty

Weight

7.6kg

Model Number

SDPH34H-024T-NBAAB

Product Features

• Optimized multi-stream workflows
• Daisy-chaining for up to 5 additional devices
• Built-in hardware RAID

In The Box

• G-RAID SHUTTLE 4 Storage System
• Thunderbolt™ 3 Cable (USB-C™ compatible)
• IEC Power Cable
• Quick Start Guide

Compatibility

• macOS 11+
• Windows 10+ (via reformat)

Capacity

48TB

Connector

• Thunderbolt 3
• USB-C

Interface

Disk Speed (RPM)

7200 RPM

Dimensions (L x W x H)

9.75" x 6.85" x 10.5"

Warranty

5-Year Limited Warranty

Weight

7.4kg

Model Number

SDPH34H-048T-NBAAB

Product Features

In The Box

Compatibility

Capacity

72TB

Connector

• Thunderbolt 3
• USB-C

Interface

Disk Speed (RPM)

7200 RPM

Dimensions (L x W x H)

9.75" x 6.85" x 10.5"

Warranty

5-Year Limited Warranty

Weight

7.5kg

Model Number

SDPH34H-072T-NBAAB

Product Features

In The Box

Compatibility

Capacity

80TB

Connector

• Thunderbolt 3
• USB-C

(In default RAID 5) - Up to 640MB/s

(In default RAID 5) - Up to 800MB/s

Interface

Disk Speed (RPM)

7200 RPM

Dimensions (L x W x H)

9.75" x 6.85" x 10.5"

Warranty

5-Year Limited Warranty

Weight

16lbs

Model Number

SDPH34H-080T-NBAAB

Product Features

In The Box

Compatibility

Capacity

96TB

Connector

• Thunderbolt 3
• USB-C

(In default RAID 5) - Up to 700MB/s

(In default RAID 5) - Up to 850MB/s

Interface

Disk Speed (RPM)

7200 RPM

Dimensions (L x W x H)

9.75" x 6.85" x 10.5"

Warranty

5-Year Limited Warranty

Weight

16.49lbs

Model Number

SDPH34H-096T-NBAAB

Product Features

In The Box

Compatibility

Capacity

104 TB

Connector

• Thunderbolt 3
• USB-C

Up to 700MB/s

Up to 850MB/s

Interface

Disk Speed (RPM)

7200 RPM

Dimensions (L x W x H)

9.75" x 6.85" x 10.5"

Warranty

5-Year Limited Warranty

Weight

17.11lbs

Model Number

SDPH34H-104T-NBAAB

Product Features

In The Box

Compatibility

Model Numbers

24TB: SDPH34H-024T-NBAAB

48TB: SDPH34H-048T-NBAAB

72TB: SDPH34H-072T-NBAAB

80TB: SDPH34H-080T-NBAAB

96TB: SDPH34H-096T-NBAAB

104 TB: SDPH34H-104T-NBAAB

Model Numbers

24TB: SDPH34H-024T-NBAAB

48TB: SDPH34H-048T-NBAAB

72TB: SDPH34H-072T-NBAAB

80TB: SDPH34H-080T-NBAAB

96TB: SDPH34H-096T-NBAAB

Disclosures

1. As used for storage capacity, 1GB = 1 billion bytes and 1TB = one trillion bytes. Actual user capacity may be less, depending on operating environment. For RAID products, storage capacity is based on RAID 0 mode.
2. Based on read speed. As used for transfer rate, megabyte per second (MB/s) = one million bytes per second. Performance will vary depending on your hardware and software components and configurations.
